220V Stability Temperature Tester with 1-Year Warranty Salt Fog Humidity Simulation Climatic Chamber

DONGGUAN YUYANG INSTRUMENT CO., LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

220V Stability Temperature Tester with 1-Year Warranty Salt Fog Humidity Simulation Climatic Chamber

  • 1
  • 2
  • 3

Brand Name : YUYANG

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C,T/T,Western Union

Supply Ability : 2 sets per month

Delivery Time : 15-20 work days

Packaging Details : Plywood Case

Model Number : YYE117

Certification : ISO: 3768, 3769, 3770; ASTM: 8117, B268

Place of Origin : China

Product Name : 220V Stability Temperature Tester with 1-Year Warranty Salt Fog Humidity Simulation Climatic Chamber

Usage : Salt Spray Test Chamber

Test Chamber Temperature : 35±1°C (NSS ACSS), 50±1°C (CASS)

Saturated Air Barrel Temperature : 47±1°C (NSS ACSS), 63±1°C (CASS)

Laboratory Relative Humidity : 85% RH Or More

Tester Chamber Volume : 108L, 270L, 480L, 800L, 1200L

Highlight : Salt Spray Test Chamber, Salt Spray Test Chamber, Corrosion Testing Apparatus

Contact Now

220V Stability Temperature Tester with 1-Year Warranty Salt Fog Humidity Simulation Climatic Chamber


Global Standards Compliance

Engineered to meet critical corrosion testing protocols demanded by quality assurance teams worldwide:
Primary Standards: ASTM B117 (Operational Practice), ISO 9227, ISO 7253, ASTM G85
Extended Validation: GB/T 2423.17-18, GB/T 10125, JIS H8502, IEC 68-2-11/52, CNS 4158-4159
CASS/NSS Testing: Certified for copper-accelerated acetic acid salt spray (GB/T 12967.3)


Material Durability Validation
Precision testing for:
• Metallic Coatings: Zinc plating, stainless steel components
• Protective Finishes: Saltwater-resistant paints, powder coatings
• Industrial Components: Electronic parts, metal substrates, fabricated products


Advanced Engineering Design

  1. Transparent Polymeric Enclosure - Impact-resistant observation window

  2. Zero-Leak Sealing System - Triple-layer water seal technology

  3. Precision Atomization

    • Tower spray mechanism with non-clogging nozzles

    • Adjustable settlement (1.0-2.0 ml/80cm²/hr)

    • Integrated solution filtration

  4. Automated Climate Control

    • Independent chamber/saturation/brine temperature regulation

    • ±0.5°C fluctuation control

  5. Reinforced Construction - Imported PP/PVC panels (15-year corrosion warranty)


Main technical parameters :


Model YY1015-60 YY1015-90 YY1015-120
Inner box size: ( L×W×H ) cm 60×40×45 90×60×50 120×100×50
Outside box size: ( L×W×H ) cm 107×60×118 141×88×128 190×130×140
Equipment material: P.V.C & P.P
Temperature range: 35°C~55°C
Temperature fluctuations: ≤±0 . 5°C
Temperature uniformity: ≤±2°C
Temperature precision: ±1°C
Test chamber temperature: NSS ACSS 35±1°C CASS : 50±1°C
Saturated air barrel temperature: NSS ACSS 47±1°C CASS 63±1°C
Brine temperature: 35°C±1°C
Spray quantity: 1 . 0~2 . 0 ml / 80cm2 / hr
PH: NSS ACSS6 . 5~7 . 2 CASS 3 . 0~3 . 2
Lab volume: 108L 270L 600L
Brine tank capacity: 15L 25L 40L
Power: 1AC220V , 10A 1AC220V , 15A AC 1 , 220V , 30A
Safety Devices: Overheating prevention circult-breaker,dehydration and
overheating prevention mechanism,breakdown indicator light
Standard accessories: Test salt, measure bucket, tool etc 1 set


Smart Control System
• Omron programmable controller with calendar timing
• Tri-color operational status indicators
• Self-diagnosis + EMO emergency stop
• Defogging function for post-test inspection
• Automatic water replenishment system


Safety & Reliability
• Thermal overload protection
• Dehydration cutoff mechanism
• Fault early-warning system with resolution guidance
• Power failure recovery protocol


Operational Flexibility
• Multiple spray modes: Continuous, intermittent, cyclic
• Material testing: NSS, AASS, CASS protocols


Industry Applications
Validates corrosion resistance for:

  • Automotive components

  • Marine hardware

  • Electronic enclosures

  • Architectural finishes
